The MegaPulse 1.2×50/8×20-2P PC 2 ohm is our 2kV, 1kA combination tester, with a 30 second cycle time. It can produce a combination test waveform at 2 ohms 2kV, in tolerance with EN 60060.
The MegaPulse 1.2×50/8×20-2P PC 2 ohm features ungrounded outputs, and is acceptable for powered testing when used with a suitable CDN.
Phase control allows pulse insertion at 0, 90, 180 and 270 degrees for powered testing.
The MegaPulse 1.2×50/8×20-2P PC 2 ohm is equipped with a relay allowing switch selected polarity output. With the switch selected polarity output, users may opt for computer control via our option TestMinder MegaPulse, or PLC guided operation with our Relay Isolated Control board.
The tester charges in less than 30 seconds. Sold with a one year warranty and calibrated to NIST Standards. A2LA Cal available at extra charge.
Waveforms can be viewed in the Manuals Section below.
2000V/1000A peak, GR-1089 1st Level AC Lightning, and others requiring powered pulse insertion at specific areas of the mains waveform. CDN required when used for powered testing.
