The newest product of our Hipot Line Testers, the UL Listed HT-S series hipot now comes with an adjustable ground continuity test in range of 0.08-1.50Ω, and Auto-offset for test leads up to 1.00Ω. Performs 2000Vac / 2800Vdc Hipot Test. Neutral/Hot to Ground Leakage current test up to 20mAac/5mAdc. Easy to use and connect. Ships complete with cables, manual, and a Calibration Certificate. Made in the USA. Calibration and repair services available. Not sure – contact us!
HT-3000S:
SKU: 00-HT3000SHipot Tester
2000Vac @ 20mA
2800Vdc @ 5mA
Adjustable Ground Continuity
UL Listed!
2000Vac @ 20mA
2800Vdc @ 5mA
Adjustable Ground Continuity
UL Listed!
$1,890.00
Hipot Tester, performs the Ground continuity, Leakage and breakdown test.
UL Listed!
Hipot Tester
2000Vac @ 20mA
2800Vdc @ 5mA
Adjustable Ground Continuity
UL Listed!
2000Vac @ 20mA
2800Vdc @ 5mA
Adjustable Ground Continuity
UL Listed!
$1,890.00
Features
- High precision leakage current, duration and ground continuity settings.
- Allows no load setup of leakage current and test dwell times.
- Once entered, ground continuity setting, leakage current and test dwell times can be referenced on the front panel display when unit is not testing.
- Leakage currents can be set from 1-20mAac/1-5mAdc in 0.1mA increments.
- Dwell times can be set from 1-60 seconds in 1 second increments.
- Two tests with one setup. Conducts UL/CSA Ground continuity and Hipot tests with one setup, so no additional equipment is needed.
- Small and light. 9.25″ wide x 4.75″ high x 10″ deep. 11 lbs. But rugged enough to test manufactured housing.
- Ground continuity check is defeatable for testing two-wire products.
- Easy equipment connections. Plug your equipment right into the NEMA plug on the front panel. No adapters needed!
- Optional J2 and J3 cords allow connection of pigtail power leads.
- Simple test outcome judgement. Green lights mean pass – red lights mean fail. Failing tests sound a buzzer as well.
- Ready for your UL Inspector out of the box.
- NIST Traceable Calibration Certificate to MIL-STD45662-A is included. Cal cert is in accordance with UL guidance.
- Operation Instructions are printed on the rear panel for easy reference.
- In-depth testing. Both true Arc Dectection and Leakage Current circuits test the product to find problems.
- RED lights and a buzzer leave no question if a failure has occurred.
- Expandable for TUV/European Agency Testing. Can be connected to our GF-30AC-T Ground Bond Tester with optional TEST-LINK™.
- Easy shift-by-shift Function Test. Compatible with our Patented function checker, the HTT-1and HTT-1R (With 0.1Ω Ground check Pass/Fail Setup).
Specifications
TESTING CIRCUITRY
Test Type: AC/DC.
Max. Output Voltage: 2000Vac/2800Vdc.
Leakage Current: 1-20mAac/1-5mAdc, 0.1mA increments.
Ground Continuity: 0.08Ω-1.50Ω, 0.01Ω increments, Defeatable.
Ground Cont. Min. Current: 100mA.
Breakdown Detect: Independent High Frequency Circuit (50KHz–500KHz).
Transformer Power: <500VA.
Leakage Current Detect: Independent Low Frequency Circuit.
Ramp Time Range: 1-5 Seconds.
Test Time Range: 1-60 Seconds.
Discharge Time: <7ms for AC, <1.3s for max DC at open circuit.
Display: 4 Digits LED Display.
Voltage Meter Accuracy: ±2%.
Leakage Accuracy: ±0.1mA.
Duty Cycle: 100%.
Pass/Fail Repeatability: ±3%.
ELECTRICAL
Rated Input Voltage: 120Vac.
Frequency: 60Hz.
Fuse: 1A, 250V, time delay, 5x20mm.
SAFETY
Safety Interlock: 2-pin terminal block on rear panel; shorted for operation. (Optional)
Output Voltage Indicator: Front panel meter directly connected to High Voltage.
Failure Indicator: Visual; provided by red LED’s, Audible; provided by buzzer.
Test automatically terminated on failure.
OUTPUTS
NEMA 5-15R: High Voltage output for easy DUT connection (N/A on HT-4200S model).
RETURN: 4mm Socket (XEF-1RR), 1000V, CAT IV, 24A, Black.
H.V. OUTPUT: 4mm Socket, 5000V, Red.
